Connection to standard 21/27 water supply.
Screen printing available for your establishment (depending on quantity).
Food grade reinforced blue hose, resistant to 70°C and 20 bars, 10 m long.
Central unit version for 1 product for 5 litre canister, hose length 10 m.
Central unit supplied with a complete connection kit, 1 x 5-litre jerrycan holder and a shock-resistant gun.
Excellent resistance to detergents of the valve, nozzles and plastic injector.
Filtering anti-pollution valve.
Gun with high shock protection, resistant to 80°C and 25 bar.
Control unit certified and approved by ACS (France), DVGW (Germany), SVGW (Switzerland), BELGAQUA (Belgium), and KIWA (Netherlands). Wall mounting with three screws.
Features of the cleaning and disinfection unit
- Non-deformable and easily cleanable PVC shell
- Wash hose support integrated into the frame
- PP Venturi injector compatible with most chemicals, easily removable
- Easily removable non-return valve, ceramic ball, Hastelloy® spring and EPDM O-ring (FPM on request)
- Flexible stainless steel hose resistant to 110°C - 18 bar
- Integrated anti-pollution valve type CA (NF double check valve AR on request)
- Product suction line(s) in Tubclair® tubing (Tygon® tubing on request)
- Dilution ratio: 0.5 to 11% Working pressure: 2 to 6 bar Working temperature: 50°C maximum
- Universal pictograms for use and safety
- Device certified according to EN1717 directive, if CA valve.
Important:
The units are supplied as standard with a non-return valve with an EPDM seal (ref: LB000113) for basic products. For use with acidic products , it is necessary to replace the valve with a more robust model with an FPM seal (ref: LB000112).
Use of a chemical product with a pH ranging from 1 to 6 (ACID) = equipped with a YELLOW valve (FPM seal).
Use of a chemical product with a pH ranging from 7 to 14 (ALKALINE) will require a BLACK valve (EPDM seal).
Benefits:
- Operates without electricity or compressed air
- Direct connection to a water supply tap
- Reduced maintenance costs thanks to quick and tool-free replacement of wear parts (Venturi injector, AR valve(s))
- Guarantee of correct dilution and controlled consumption of chemical products
